WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails

Name: WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails
Brand: HIWIN
Price: 1 USD

Cheap WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails for sale

Brand Name : HIWIN

Model Number : WEH21CA

Certification : DE1924083895474

Place of Origin : CHINA TAIWAN

MOQ : 10

Price : 1-100 USD

Payment Terms : T/T,L/C,D/A,D/P,Western Union

Supply Ability : 100000 pcs / per month

Delivery Time : 1-7 work days

Packaging Details : Small or with carton box, Bulk order with Wooden box

Series : WE

Model Size(mm) : 21mm

No. of Blocks per Rail : 1

Rail Mounting Type : R- Mounting From Top

Rail Length(mm) : Max 4000mm

Preload Class : Z0-Very Light Preload , ZA-Light Preload , ZB-Medium Preload

Material : SNCM220 Carbon Steel

Dust Protection : SS-standard

Y -Symmetrical (E1＝E2) First hole dimension : Y= Symmetrical （E1=E2)

Installation : Easy

Application : Automation devices, Blow Moulding machines, Precision measuring equipment

Smoothness : Smooth

Contact Now

①HIWIN WEH21CA Linear Guideway 21mm Adjustable Conveyor Guide Rails

The HIWIN WEH21CA Linear Guideway is a game-changer in the realm of automation. It features a 21mm width, making it a versatile choice for various automated systems. In industrial automation setups, it serves as a reliable foundation for adjustable conveyor guide rails. This allows for seamless transportation of goods along production lines, ensuring each item moves precisely where it needs to go. For instance, in electronics assembly, it helps route circuit boards smoothly through different stages of production, from component installation to final testing. In automotive manufacturing, it enables the smooth conveyance of car parts, enhancing the overall efficiency of the assembly process. Its adaptability and precision make it an essential tool for any automated operation looking to optimize productivity and streamline workflows.

②Drawing of WEH21CA

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails

③Model Number of WE Series

④Construction of WE Series

1.Rolling circulation system: Block, rail, end cap and retainer

2.Lubrication system: Grease nipple and piping joint

3.Dust protection system: End seal, bottom seal, cap and scraper.

⑤Features of WE series
The WE series features equal load ratings in the radial, reverse radial and the lateral direction with contact points at 45degrees. This along with the wide rail, allows the guide way to be rated for high loads, moments and rigidity. By design, it has a self-aligning capacity that can absorb most installation errors and can meet high accuracy standards.The ability to use a single rail and to have the low profile with a low center of gravity is ideal where space is limited and/or high moments are required.

⑥Actual product photo

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails

⑦Measurement drawing

⑧HIWIN series

⑨top product recommendation
